In stock
A two-cartridge solution featuring an innovative, modular design that effectively eliminates dust, smoke and other airborne contaminates from your work environment.
The iVAC Bagless Self-Cleaning Dust Collector series is an efficient debris removal system that requires minimal maintenance as a result of its large dust holding tray. These units feature not only a small footprint, but also a medical grade HEPA filter that is 99.97% efficient, a high-speed motor, improved maintenance access, and quiet operation. The iVAC comes equipped with our digital iSeries control panel which empowers operators with variable speed control, visual status indicators, and audible alarms for filter status.
The iVAC Bagless Self-Cleaning Dust Collector series is an efficient debris removal system that requires minimal maintenance as a result of its large dust holding tray. These units feature not only a small footprint, but also a medical grade HEPA filter that is 99.97% efficient, a high-speed motor, improved maintenance access, and quiet operation. The iVAC comes equipped with our digital iSeries control panel which empowers operators with variable speed control, visual status indicators, and audible alarms for filter status.
This collection unit is engineered for resin-based dust and debris applications with the following benefits:
iVAC’s standout features extend far beyond its self-cleaning capabilities. These are just a few:
The iVAC can be equipped with added options for increased functionality, including:
| Product Number | Pressure | CFM | Volts/Phase/Hz | Amps | Shipping Weight | Width | Height | Depth | Noise(dB) | Max Debris Capacity (in3) | Filter Sequence | Filter Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-0052-0711 (Dual Infinity motors/Dual 2″ inlets) |
90″ WC | 282 | 120/1/160 | 12 | 90lbs (41kg) |
16″ | 26″ | 20″ | 52dB(A) | 1200 | •4″ Main Filter F315 •2″ HEPA Filter F074 |
•MERV 12 •MERV 17 |
| 1-0052-0712 (Dual Infinity motors/Single 4″ inlet) |
90″ WC | 282 | 120/1/160 | 12 | 90lbs (41kg) |
16″ | 26″ | 20″ | 52dB(A) | 1200 | •4″ Main Filter F315 •2″ HEPA Filter F074 |
•MERV 12 •MERV 17 |
| 1-0052-4711 (Single Brushless motor/Dual 2″ inlets) |
54″ WC | 220 | 120/1/160 | 12 | 90lbs (41kg) |
16″ | 26″ | 20″ | 52dB(A) | 1200 | •4″ Main Filter F315 •2″ HEPA Filter F074 |
•MERV 12 •MERV 17 |
| 1-0052-4712 (Single Brushless motor/Single 4″ inlet) |
54″ WC | 220 | 120/1/160 | 12 | 90lbs (41kg) |
16″ | 26″ | 20″ | 52dB(A) | 1200 | •4″ Main Filter F315 •2″ HEPA Filter F074 |
•MERV 12 •MERV 17 |
| Product Number | Pressure | CFM | Volts/Phase/Hz | Amps | Shipping Weight | Width | Height | Depth | Noise(dB) | Max Debris Capacity (in3) | Filter Sequence | Filter Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-0040-0712 (Single 3″ inlet) |
90″ WC | 141 | 120/1/160 | 8 | 43lbs (20kg) |
10″ | 22″ | 15″ | 58dB(A) | 1200 | •4″ Main Filter F301 •1″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| 1-0040-0711 (Dual 1.5″ inlets) |
90″ WC | 141 | 120/1/160 | 8 | 43lbs (20kg) |
10″ | 22″ | 15″ | 58dB(A) | 1200 | •4″ Main Filter F301 •1″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| 1-0040-4712 (Single Brushless motor/Single 3″ inlet) |
54″ WC | 110 | 120/1/160 | 8 | 43lbs (20kg) |
10″ | 22″ | 15″ | 58dB(A) | 1200 | •4″ Main Filter F301 •1″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| 1-0040-4711 (Single Brushless motor/Dual 1.5″ inlets) |
54″ WC | 110 | 120/1/160 | 8 | 43lbs (20kg) |
10″ | 22″ | 15″ | 58dB(A) | 1200 | •4″ Main Filter F301 •1″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| Product Number | Pressure | CFM | Volts/Phase/Hz | Amps | Shipping Weight | Width | Height | Depth | Noise(dB) | Max Debris Capacity (in3) | Filter Sequence | Filter Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1-0051-0711 (Single Infinity motor/Dual 1.5″ inlets) |
90″ WC | 141 | 120/1/160 | 8 | 43lbs (20kg) |
15″ | 24.4″ | 20″ | 53dB(A) | 1200 | •4″ Main Filter F301 •2″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| 1-0051-0712 (Single Infinity motor/Single 3″ inlet) |
90″ WC | 141 | 120/1/160 | 8 | 43lbs (20kg) |
15″ | 24.4″ | 20″ | 53dB(A) | 1200 | •4″ Main Filter F301 •2″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| 1-0052-4711 (Single Brushless motor/Dual 2″ inlets) |
54″ WC | 220 | 120/1/160 | 12 | 43lbs (20kg) |
15″ | 24.4″ | 20″ | 53dB(A) | 1200 | •4″ Main Filter F301 •1″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
| 1-0052-4711 (Single Brushless motor/Dual 2″ inlets) |
54″ WC | 220 | 120/1/160 | 12 | 43lbs (20kg) |
15″ | 24.4″ | 20″ | 53dB(A) | 1200 | •4″ Main Filter F301 •1″ HEPA Filter F191S |
•MERV 12 •MERV 17 |
No data available.
