Before You Begin

Designate a location near the operator where the unit will be placed that is sufficiently close to a grounded power source.

Unpacking Unit

1. Inspect carton for any possible damage during transit.
2. Remove packing material.
3. Do not tip or invert while handling.
4. You’ll find the item serial number, model and electrical ratings located on the nameplate. Write down this information on the provided Maintenance Record found in your owner’s manual or your own designated preventative maintenance system.

Installation

1. Connect to air inlet.
   1. If possible, use smooth bore ducting as they have less airflow resistance.
   2. Inlet ducts should be full diameter. Changes in section and size should be gradual.
2. Connect pipes to water supply and drain fittings. (Refer to Section 2.1 in owner’s manual.)
3. Connect power. (Refer to Appendix 1A in owner’s manual.)
4. Verify motor rotation is clockwise when looking top down from unit.
5. Fill Collector’s water basin to indicated level.

Before you use your unit, you’ll want to perform a function test to verify it’s in working order. Do the following:

1. Turn the power switch to On.
2. Look to confirm that the unit is level and stable. You’ll also want to verify that nothing is obstructing the extraction path and that there is enough water in basin.
3. Listen closely to the motor and suction sound of unit. Confirm that they are in within the expected volumes.
4. By placing your hand on top of the unit, feel for any unexpected vibration. Place your hand in front of the intake surface to confirm the expected levels of suction.

Perform Daily Inspections

1. Inspect surfaces for dust. Wipe down as needed.
2. Inspect filter panels for dust buildup. Service or replace as needed.
3. Check to see if unit has sufficient water. Refill to meet water level if needed.
4. Check for moisture by turning unit on and placing hand above exhaust stack. If excess moisture passes through blower, drain water from basin to indicated level.

Exchange Water (Every 2 Weeks or 30 Operating Hours)

1. 1. Remove water using drain outlet.
      1. Be careful to keep water and waste away from electrical equipment.
      2. Consult local regulators on the safe handling, disposal and treatment of material waste.
   2. Remove grating.

1. 1. Remove scrubber tree.

1. Using a Diversitech WV Sludge Vacuum or equivalent, remove semi-solid build-up at the bottom of the basin.
   IMPORTANT: Consult local regulators on the safe handling, disposal and treatment of material waste.
2. Use pressure washer or plastic bristle brush to clean basin (no metallic brushes).
3. Turn machine on to allow Auto-Level Control System to fill the basin or fill manually.

Perform Annual Inspections

1. Clean labels and exterior surfaces.
2. Wash cabinet internal assemblies with warm water and mild detergent. Allow 12 hours to dry before use.
3. Check controls for loose wiring.
4. Examine motors for wear.
